Description
The NanoCal Precision Surface Mapper redefines dimensional inspection and surface diagnostics for engineers, technicians, and advanced makers. Featuring an integrated ultra-high resolution laser interferometry sensor combined with a 3-axis nano-positioning stage, the NanoCal delivers sub-micron accuracy surface profiles up to a 100mm x 100mm scanning area with 0.2µm vertical resolution. The device employs proprietary Adaptive Reflectometry Calibration™ technology, which automatically adjusts sensor parameters in real time to compensate for material reflectivity and surface texture variations—eliminating manual recalibration and reducing measurement errors in complex environments.
Designed for portability without sacrificing precision, the NanoCal is housed in a lightweight magnesium alloy frame measuring just 180mm x 120mm x 50mm, weighing under 900g. It connects via USB-C with proprietary high-throughput data transfer and supports integration with popular CAD and metrology software through an open API. An intuitive touchscreen interface and onboard analytical suite enable technicians to perform immediate diagnostics, defect identification, and generate detailed surface reports in various export formats including ISO 25178 compliant surface texture data.
Key technical specifications:
– Measurement Range: 100mm x 100mm
– Vertical Resolution: 0.2µm
– Lateral Resolution: 0.5µm minimum
– Sensor Tech: Laser Interferometry combined with Photonic Phase Detection
– Positioning Stage: Closed-loop piezo nano-actuators
– Interface: USB-C, Wi-Fi module option
– Dimensions: 180mm x 120mm x 50mm
– Weight: 880g
– Software: NanoCal Suite (Windows/macOS/Linux compatible)
Whether inspecting precision machined parts, semiconductor wafers, or layered composites, the NanoCal Precision Surface Mapper empowers users with unmatched accuracy, repeatability, and ease-of-use—all in a compact form factor designed for both bench and field deployment.
